The Backbone of Electrical Infrastructure

At Square EIC, we provide high-quality, heavy-duty cable tray systems designed to support, route, and protect electrical power, data, and control cables. Our systems ensure organized cable management, improved airflow, and easy maintenance access for any facility.

• General Description: A complete range of cable trays (Perforated, Ladder, and Solid Bottom) manufactured from premium materials to withstand mechanical stress and environmental corrosion. These systems are essential for distributing large volumes of cables across ceilings, floors, or walls.

• Key Technical Specs:

  • Material Options: Pre-galvanized steel, Hot-dip galvanized (after fabrication) for maximum corrosion resistance, and Stainless Steel (304/316).

  • Types Available:

    • Perforated Type: Ideal for moderate heat ventilation and easy cable tying.

    • Ladder Type: Designed for heavy-duty power cables, providing maximum ventilation and support.

    • Solid Bottom: Offers total protection for sensitive data and communication cables.

  • Standard Thickness: Ranging from 1.0 mm to 3.0 mm depending on the load requirements.

  • Standard Lengths: Typically 2.44m or 3.0m per section, with customizable widths from 50mm to 900mm.

  • Compliance: Manufactured according to NEMA VE 1 and IEC 61537 standards for load-bearing capacity and electrical continuity.

• Why Choose Our Cable Trays?

  • Corrosion Protection: Our Hot-Dip Galvanizing process ensures long-term durability in humid or industrial environments.

  • Safety: Smooth, burr-free edges to prevent cable insulation damage during pulling and installation.

  • Full Accessory Range: We supply all necessary fittings, including 90° bends, tees, crosses, reducers, and specialized support systems (Unistrut channels and brackets).
